Specification

  • Frame – Aluminium alloy 6061, internal cable routing
  • Fork – SR SUNTOUR XCT – lockout suspension with 100mm travel
  • Frame Color – Matt Black / Glossy Grey / Glossy Green
  • Decal – Water Decal
  • Shifter – Shimano Altus M315, 2×8 Speed
  • Crank – Shimano Altus FC – M315, 175mm alloy crank, 36×2 2T chain – ring
  • Cassette – Shimano CS-HG200 8-speed cassette, 11-32T
  • Rear Derailleur – Shimano Altus RD-M310
  • Front Derailleur: Shimano Altus FD-M315
  • Bottom Bracket – Sealed Type Neco B908 BB
  • Chain – TEC C8
  • Pedals – Alloy Pedals with reflectors
  • Saddle – PU Foam, Vinyl cover, with ABS protection plate
  • Seatpost – Alloy, 30.8×2.4Tx350mm with clamp
  • Handlebar – Alloy straight type handlebar, 31.8mm 22.2×1.4T, 680 mm length
  • Headset – Neco head parts with alloy stem,31.8×28.6mm with 80mm length
  • Grips – VELO ergonomic lock-on grips
  • Rims – Double wall alloy rims 28″x14Gx36H
  • Wheel Size – S-27.5 inch, ML & L – 29 inch
  • Tire – Kenda Honey Badger
  • F/R Hub – Alloy hubs, 36H with alloy quick release
  • Spokes – C45, 14G black brass nipple
  • Brake Lever – Tektro M275
  • Brake Caliper – Tektro M275 F/R Hydraulic disc brakes
  • Rotor – Tektro, 160mm rotor disc, F/R
  • Rear kickstand
  • Tool Kit
  • Reflectors
  • Weight – 15 kilograms
  • Ideal Height – S(160-170cm), ML(170-180cm), L(175-185cm
  • Max Weight – 140 kilograms (including bike weight)

Geometry & Size

M
Height (cm) 162-175
Seat Tube Length (A)
456
17.95
Seat Tube Angle (B)
73
2.87
Effective Seat Tube Angle (C)
73
2.87
Head Tube Length (D)
105
4.13
Head Tube Angle (E)
69
2.72
Effective Top Tube (F)
585
23.03
Bb Height (G)
303
11.93
Bb Offset (H)
47
1.85
Chainstay Length (I)
430
16.93
Wheelbase (J)
1086.1
42.76
Frame Reach (K)
402.2
15.83
Frame Stack (L)
597.8
23.54
Standover Height (M)
747
29.41
Pick Your Size

S, ML, L

Choose Color

Glossy Green, Glossy Grey, Matt Black
