Marlin GRS100
₹46,990.00
Marlin GRS100, is an all-terrain hybrid bike suited for roads and gravel trails. 1x Groupset for easy shifting; the reliable hydraulic disc brakes provide you with a powerful stopping in any condition and easier maintenance; and take you wherever you’re heading faster than before with its low rolling resistance tire. This bike is equipped with a narrow wide chain ring that helps you against frequent chain drop. As you cruise faster and farther, the Marlin GRS100 brings you the best riding feels ever.
- Frame – Aluminum alloy 6061, internal cable routing, dropper post ready
- Fork – SR Suntour NEX HLO 700, 63MM travel with hydraulic lockout
- Frame Color – Matt Black / Viper Red / Chameleon
- Decal – Water Decal
- Shifter – Shimano Deore M4100, 1×10 Speed
- Crank – Marlin G3 Alloy 2 piece HollowTech Crank, 104 BCT, 38T with narrow wide chain-ring
- Cassette – Shimano Deore M4100 11-42T
- Rear Derailleur – Shimano Deore M4120
- Bottom Bracket – HollowTech Sealed BB
- Chain – KMC X10 116L
- Pedals – Alloy Pedals with reflectors
- Saddle – PU Foam, Vinyl cover, with ABS protection plate
- Seatpost – Alloy, 30.8×2.4Tx350mm with clamp
- Handlebar – Alloy31.8mm, 20mm rise with 680mm(S,M,L) and 720mm(XL)
- Headset – Neco thread-less integrated headset
- Stem: Alloy Stem with 7°rise, 60mm length (S, M) / 80mm (L, XL)
- Grips – Ergonomic lock-on grips
- Rims – Double wall alloy rims 700C*40x32H with 3M reflective sticker
- Wheel Size – 700C
- Tire – KENDA K1083A 700C*40C
- F/R Hub – Alloy Sealed Bearing hubs with alloy quick release
- Spokes – High Carbon Steel
- Brake Lever – Tektro M275
- Brake Caliper – Tektro M275 F/R Hydraulic disc brakes
- Rotor – Tektro, 160mm rotor disc, F/R
- Rear kickstand
- Tool Kit
- Reflectors
- Weight – 14 kilograms
- Ideal Height – S(160-170cm), M(165-175cm), L(170-180cm), XL(180-190cm)
- Max Weight – 125 kilograms (including bike weight)
Geometry & Size
A brief explanation of geometry is placed here. The geometry image below will stay / freeze.
| S | M | L | XL | |
|---|---|---|---|---|
| Height | 160-170 (cm) 63-67 (inch) |
165-175 (cm) 65-69 (inch) |
170-180 (cm) 67-71 (inch) |
180-190 (cm) 71-75 (inch) |
| Seat Tube Length(A) | 400 (cm) 15.75 (inch) |
432 (cm) 16.97 (inch) |
417 (cm) 18.5 (inch) |
516 (cm) 20.31 (inch) |
| Seat Tube Angle (B) | 74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
| Effective Seat Tube Angle (C) | 74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
74 (cm) 2.91 (inch) |
| Head Tube Length (D) | 100 (cm) 3.94 (inch) |
100 (cm) 3.94 (inch) |
110 (cm) 4.33 (inch) |
110 (cm) 4.33 (inch) |
| Head Tube Angle (E) | 71 (cm) 2.8 (inch) |
71 (cm) 2.8 (inch) |
71 (cm) 2.8 (inch) |
71 (cm) 2.8 (inch) |
| Effective Top Tube (F) | 558 (cm) 21.97 (inch) |
588 (cm) 11.34 (inch) |
616 (cm) 24.25 (inch) |
641 (cm) 25.24 (inch) |
| Bb Height (G) | 280.1 (cm) 11.03 (inch) |
280.1 (cm) 11.03 (inch) |
280.1 (cm) 11.03 (inch) |
280.1 (cm) 11.03 (inch) |
| Bb Offset (H) | 70 (cm) 2.6 (inch) |
70 (cm) 2.6 (inch) |
70 (cm) 2.6 (inch) |
70 (cm) 2.6 (inch) |
| Chainstay Length (I) | 440 (cm) 17.32 (inch) |
440 (cm) 17.32 (inch) |
440 (cm) 17.32 (inch) |
440 (cm) 17.32 (inch) |
| Chainstay Length (I) | 1043.12 (cm) 41.07 (inch) |
1073.12 (cm) 42.25 (inch) |
1101.26 (cm) 43.36 (inch) |
1126.26 (cm) 44.34 (inch) |
| Frame Reach (K) | 385 (cm) 15.16 (inch) |
415 (cm) 16.34 (inch) |
440 (cm) 17.32 (inch) |
465 (cm) 18.31 (inch) |
| Frame Stack (L) | 602.7 (cm) 23.73 (inch) |
602.7 (cm) 23.73 (inch) |
612.2 (cm) 24.10 (inch) |
612.2 (cm) 24.10 (inch) |
| Standover Height (M) | 688.2 (cm) 27.09 (inch) |
711.8 (cm) 28.02 (inch) |
744.7 (cm) 29.32 (inch) |
780.6 (cm) 30.73 (inch) |
| Choose Color | Chameleon, Matt Black, Viper Red |
|---|---|
| Pick Your Size | S, M, ML, L, XL |
